Product selection specification
Vertical (bladder type) pressure tank | |||||
Device Model | Specification, can body diameter and height (mm) | total volume V（m³） | Adjustable volume Vt（m³） | work pressure （Mpa） | Net weight （kF） |
NZP-400 | 400*1460 | 0.2 | 0.06 | 0.6 | 175 |
1.0 | 190 | ||||
1.6 | 230 | ||||
NZP-600 | 600*1820 | 0.35 | 0.11 | 0.6 | 206 |
1.0 | 223 | ||||
1.6 | 265 | ||||
NZP-800 | 800*2250 | 0.82 | 0.26 | 0.6 | 330 |
1.0 | 350 | ||||
1.6 | 520 | ||||
NZP-1000 | 1000*2550 | 1.40 | 0.49 | 0.6 | 500 |
1.0 | 613 | ||||
1.6 | 850 | ||||
NZP-1200 | 1200*2780 | 2.50 | 0.80 | 0.6 | 700 |
1.0 | 943 | ||||
1.6 | 1187 | ||||
NZP-1400 | 1400*2950 | 3.46 | 1.20 | 0.6 | 900 |
1.0 | 1200 | ||||
1.6 | 1600 | ||||
NZP-1600 | 1600*3360 | 5.00 | 2.00 | 0.6 | 1220 |
1.0 | 1802 | ||||
1.6 | 2210 | ||||
NZP-2000 | 2000*3850 | 8.53 | 3.10 | 0.6 | 1700 |
1.0 | 2600 | ||||
1.6 | 3700 | ||||
