Plate Materials
Material Name & Grade | Suitable Medium |
Stainless Steel (SU304,SUS316,SUS316L,SUS321,SUS310S,SUS317L) | General fluids with low chloride ion content |
Industrial Pure Titanium TA1 | Solutions with high chloride ion content, such as seawater |
Hastelloy | Chlorinating acids,e.g., sulfuric acid, mixed acids |
Acid-Resistant Steel RS-2 | Strong acids,e.g., concentrated sulfuric acid, nitric acid |
Gasket Materials
Material | Operating Temperature | Suitable Medium |
EPDM Rubber (E) | -50℃~150℃ | Water, general organic/inorganic acids, alkalis,and chemical media |
Nitrile Rubber (N) | -20℃~110℃ | Water, oils, hydrocarbons, aldehydes, andgeneral corrosive media |
Food & Pharmaceutical Rubber (S) | -20℃~120℃ | Food materials, pharmaceutical industrymaterials |
Fluoro Rubber(F) | 0℃~180℃ | Organic solutions, acids, alkalis, alcohols, oils |
Chloroprene Rubber (C) | -40℃~100℃ | Alkalis and some acids |
Silicone Rubber (Q) | -65℃~230℃ | Some oils, alcohol |
