Technical parameters of ground source heat pump air conditioning hydraulic module
Technical parameters/model | DMK03 | DMK05 | DMK09 | DMK12 | DMK18 | DMK25 | ||
air conditioning system | System Name | F3-3 | F5-3 | F10-2 | F10-3 | F15-2 | F25-2 | |
rated flow | m³/h | 1.2-2.8 | 3.0-5.0 | 6.0-12.0 | 12.0-14.0 | 14.0-21.0 | 18.0-29.0 | |
pump head | m | 28-22 | 26-21 | 28-21 | 32-22 | 30-21 | 32-22 | |
pump power | KW | 0.45 | 0.67 | 1.2 | 2.2 | 2.2 | 4 | |
pressure drop | KPa | 5 | 5 | 5 | 5 | 5 | 5 | |
inlet and outlet pipe interface | DN25 | DN32 | DN40 | DN50 | DN50 | DN65 | ||
outlet pipe interface | DN25 | DN32 | DN40 | DN50 | DN50 | DN65 | ||
buried pipe system | System Name | F3-3 | F5-3 | F10-2 | F10-3 | F15-2 | F25-2 | |
rated flow | m³/h | 1.2-2.8 | 3.0-5.0 | 6.0-12.0 | 12.0-14.0 | 14.0-21.0 | 18.0-29.0 | |
pump head | m | 28-22 | 26-21 | 28-21 | 32-22 | 30-21 | 32-22 | |
pump power | KW | 0.45 | 0.67 | 1.2 | 2.2 | 2.2 | 4 | |
pressure drop | KPa | 5 | 5 | 5 | 5 | 5 | 5 | |
inlet and outlet pipe interface | DN25 | DN32 | DN40 | DN50 | DN50 | DN65 | ||
outlet pipe interface | DN25 | DN32 | DN40 | DN50 | DN50 | DN65 | ||
Rated power of the unit | KW | 0.45+0.45 | 0.67+0.67 | 1.2+1.2 | 2.2+2.2 | 2.2+2.2 | 4.0+4.0 | |
Operating power supply form | V/HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | |
